Hydraulic tensioners
GL2×70-II
A hydraulic tensioner for conductor stringing. Review continuous tension, bull-wheel geometry and conductor dimensions together.
Download specification summary · TXT
2×65/1×130 kNMax. continuous tension
5 km/hMaximum speed
1500 mmBull-wheel diameter
Working
specifications.
Read force and speed ratings together. Maximum force and maximum speed are not a simultaneous operating point.
| Max. continuous tension | 2×65/1×130 kN |
|---|---|
| Max. intermittent tension | 2×70/1×140 kN |
| Maximum speed | 5 km/h |
| Tension at maximum speed | 2×25/1×50 kN |
| Maximum reverse pulling force | 2×60/1×120 kN |
| Bull-wheel diameter | 1500 mm |
| Maximum conductor diameter | 40 mm |
| Total weight | 10000 kg |
| Overall dimensions | 5500 × 2300 × 2700mm |
| Engine power | 77kW(103hp) |
Listed configuration
- Tension presetting with stepless speed control
- Hydraulic oil cooling system
- Grounding connection point
Additional devices
Discuss project-specific accessories and configuration with the team.
Specifications transcribed from the GALAXY catalogue. Confirm the current configuration, optional equipment and project suitability before ordering.
GALAXY Catalogue V2026 · pp. 24–25
